Van Damme Tour Grade Classic XKE pro-patch cable, black, per metre

Van Damme Pro Grade Classic XKE Pro-patch cable has been specifically designed as a 4.85mm overall diameter cable to suit Neutrik and Switchcraft bantam jacks, and other applications requiring a lower OD cable.

Its braided screen and tightly packed construction ensure that the smaller size in no way compromises the mechanical and sonic integrity.

Applications
 For mic and line level analogue balanced audio
 Bantam patch cords and bantam adaptor cables
 Shorter mic cables and XLR splitter cables
 Midi leads and other DIN connector applications
Application Notes
 Further improved outer jacket ensures cable remains flexible in sub-zero temperatures
 Tightly packed cotton fillers ensure no static build up and even capacitance
 Available in 10 colours for application or length colour coding
 95% optical coverage braided screen for excellent mechanical strength and EMI/RFI rejection
 Combination of silver plated and plain ultra-pure oxygen free copper conductors for unsurpassed
sound quality
Mechanical Specification
Conductors 7 x 0.10 mm silver plated ultra-pure oxygen-free copper
21 x 0.10 mm bare ultra-pure oxygen-free copper
Conductor size 28 x 0.10 mm, 0.22 mm2, AWG 24/28
Insulation Cross-linked polyethylene (XLPE)
Insulation diameter 1.60 ± 0.10 mm
Colour Code Red/Blue
Screen 96 x 0.10 mm braided tinned copper > 95% optical coverage
Jacket material Flexible PVC/Neoprene composite
Overall diameter 4.85 ± 0.15 mm
Bend radius 10 x overall diameter
Operating temperature -20 to +70 ⁰C
Electrical Specification
Resistance Conductor < 85 Ohm/km
Insulation > 5000 MOhm/km
Capacitance Core to core 50 pF/m
Core to screen 95 pF/m
